LC1D128P7 TeSys Deca contactor, 4P(2NO+2NC), AC-1, <=440V 25A, 230V AC coil

The TeSys Deca LC1D is a high-performance, compact contactor designed for industrial and HVAC applications. With its innovative design, ease of installation, and robust features, it meets the demands of resistive load operations up to 25A at 690V.

Key Features :

• Application : Suitable for resistive load applications in AC-1, AC-3, AC-3e, and AC-4 categories
• Poles Description : 4 poles (2NO + 2NC)
• Coil Voltage : 230V AC, 50/60 Hz
• Built-In Auxiliary Contacts : 1NO + 1NC, mechanically linked and mirror contact certified
• Rated Operational Current : 25A at ≤ 440V AC (at <60°C)
• Rated Voltage : Up to 690V AC / 300V DC

Durability & Performance :

• Mechanical durability : 15 million cycles
• Electrical Durability : 0.8 million cycles at 25A AC-1
• Operating Rate : Up to 3600 cycles/hour
• Ambient Temperature : Operates in -40°C to +60°C environments (+70°C with derating)
• Fire Resistance : 850°C conforming to IEC 60695-2-1

Compact & Flexible Design :

• Dimensions : 85mm (H) x 45mm (W) x 92mm (D)
• Mounting Options : DIN-rail or screw fixing
• Connection Type : Screw clamp terminals for flexible or solid cables

Certifications & Standards :

• Multi-standard certified (IEC, UL, CSA, CCC, EAC, Marine)
• RoHS and REACh compliant (Green Premium product)
• Conforms to IEC 60947-4-1, IEC 60335-1, and UL 60947-4-1

The TeSys Deca LC1D contactor offers exceptional reliability and efficiency, making it ideal for high-demand industrial and HVAC applications while ensuring a compact and user-friendly design.
